| Lens |
| Aperture | F1.0
|
|---|
| Focus | Fixed
|
|---|
| Lens mount | M16
|
|---|
| Lens type | 2.8/4/6 mm
|
|---|
| Aperture type | Fixed
|
|---|
|
| Network |
| Ethernet | 10/100 Mbps Self-Adaptive Ethernet
|
|---|
| Alarm Trigger | HDD error, HDD full, Illegal login, IP address conflict, Motion detection, network disconnected, video tampering
|
|---|
| API | ISAPI, ONVIF (PROFILE S, PROFILE G)
|
|---|
| Network Storage | ANR, local storage, Micro SD/SDHC/SDXC card (128G), NAS (NFS,SMB/CIFS)
|
|---|
| Protocols | 802.1X, Bonjour, DDNS, DHCP, DNS, FTP, HTTP, HTTPS, ICMP, IGMP, IPv6, NTP, PPPoE, QoS, RTCP, RTP, RTPS, SMTP, SNMP, TCP/IP, UDP, UPnp™
|
|---|
| Simultaneous Live View | Up to 6 channels
|
|---|
| User/Host | Up to 32 users,3 levels: Administrator, Operator and User
|
|---|
| Web Browser | Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari 11+ Local Service: Chrome 41.0+, Firefox 30.0+, Plug-in required live view: IE8+
|
|---|
|
| Algemeen |
| IP protection level | IP67
|
|---|
| Power consumption | 12 VDC, 0.7 A, max. 9.5 W, PoE: (802.3af, 36 V to 57 V), 0.3 A to 0.1 A, max. 11 W
|
|---|
| Working temperature | 30 °C to +60 °C
|
|---|
| Camera Dimension | Φ 105 × 290.7 mm
|
|---|
| Camera Weight | 1200 g
|
|---|
| Firmware Version | V5.5.82
|
|---|
| General Function | heartbeat, IP address filter, mirror, One-key reset, Password protection, privacy masks, three streams, Watermark
|
|---|
|
| Features |
| Application | Hik-Connect, iVMS-4200, iVMS-4500, iVMS-5200
|
|---|
|
| Video |
| Max. Resolution | 2688 × 1520
|
|---|
| Main Stream | 50Hz: 25fps (2688 × 1520, 2560 × 1440, 2304 × 1296, 1920 × 1080, 1280 × 720), 60Hz: 30fps (2688 × 1520, 2560 × 1440, 2304 × 1296, 1920 × 1080, 1280 × 720)
|
|---|
| Sub Stream | 50Hz: 25fps (640 × 480, 640 × 360, 320 × 240), 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
|
|---|
| Third Stream | 50Hz: 25fps (1920 × 1080, 1280 × 720, 640 × 360, 352 × 288), 60Hz: 30fps (1920 × 1080, 1280 × 720, 640 × 360, 352 × 240)
|
|---|
| Video Compression | H.265/H.264
|
|---|
| H.264 Type | Main Profile/High Profile
|
|---|
| H.265 Type | Main Profile
|
|---|
|
| Afbeelding |
| DNR | 3D DNR
|
|---|
| Image Enhancement | BLC/3D, DNR/HLC
|
|---|
| Image Settings | AGC, brightness, contrast, Rotate mode, saturation, sharpness, white balance
|
|---|
|
| Interface |
| Hardware Reset | Yes
|
|---|
| On-board Storage | Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
|
|---|
|
| Smart Feature-set |
| Face Detection | Yes
|
|---|
| Smart Event | Intrusion detection, Line crossing detection, Object removal detection, Unattended baggage detection
|
|---|
|
| Meer |
| Image sensor | 1/1.8" Progressive Scan CMOS
|
|---|
| Angle Adjustment | Pan: 0° to 360°, rotate: 0° to 360°, tilt: 0° to 90°
|
|---|
| Min. Illumination | 0.0014 @ (F1.0, AGC ON), 0 Lux with Light
|
|---|
| Shutter Speed | 1/3 s to 1/100000 s
|
|---|
| Slow Shutter | Yes
|
|---|
| Wide Dynamic Range | 120dB
|
|---|
|
